HOYIN
Hoyin Aluminum Oxide, Large Cutting Wheels
Hoyin Aluminum Oxide (AO) Large Cutting Wheels 14 inch 16inch 20inch(355mm,405mm,505mm) Type 1 Bonded Abrasives 1/8"(3.0mm) Thickness A30R A30S for Stationary Saw
Hoyin Aluminum Oxide (AO) Large Cutting Wheels 14 inch 16inch 20inch(355mm,405mm,505mm) Type 1 Performance Line: Performance Grade Bonded Abrasives - Cutting & Grinding Wheels - Cutting Wheels (discs) Series - 1/8"(3.0mm) Thickness A30R A30S for Stationary Saw HOYIN aluminum oxide 14 inch 16inch 20inch(355mm,405mm,505mm) large cutting wheels deliver the right combination of performance and value when cutting steel and other metals. The flat type 1 profile allows for deep cuts commonly required when cutting metal. The 1/8"(3.0mm) wheel thickness is ideal for cutting with a stationary saw. |
Hoyin Aluminum Oxide Large Cutting Wheels 14 inch 16inch 20inch(355mm,405mm,505mm) Type 1 1/8"(3.0mm) Thickness A30R A30S for Stationary Saw
FEATURES AND BENEFITS
Strong resin bond delivers a long cutting life that keeps professionals on the job longer.
White aluminum oxide grains provide an even, sharp, clean cut rate and consistent performance.
Dual reinforcement provides added strength for aggressive cutting.
Smooth outer layer reduces friction that translates to an effortless cut and less kickback during operation.
1 inch(25mm) open arbor for easy mounting.
Designed for metal stationary saws.
Best for use on carbon steel, structural steel, iron and general purpose metal use.
Hoyin Aluminum Oxide Large Cutting Wheels 14 inch 16inch 20inch(355mm,405mm,505mm) Type 1 1/8"(3.0mm) Thickness A30R A30S for Stationary Saw
P PERFORMANCE LARGE CUTTING WHEEL
STEEL/METAL HOYIN Aluminum Oxide/Long Life TYPE 1 For Stationary Saw
| Dia(inch/mm) | Thickness(inch/mm) | Grade | Max. RPM | Arbor(inch/mm) | Description | Std. Pack | Item# |
| 14in(355mm) | 1/8in(3.0mm) | A30R | 4,400 | 1"(25mm) | Long Life Cutting | 10 | 72440 |
| 16in(405mm) | 1/8in(3.0mm) | A30S | 3,850 | 1"(25mm) | Long Life Cutting | 10 | 72446 |
| 20in(505mm) | 1/8in(3.0mm) | A30S | 3,100 | 1"(25mm) | Long Life Cutting | 10 | 72447 |
| Hoyin Aluminum Oxide Large Cutting Wheels 14 inch 16inch 20inch(355mm,405mm,505mm) Type 1 1/8"(3.0mm) Thickness A30R A30S for Stationary Saw |
|
- Production Standard::
- ANSI B7.1 ,EN12413
- Application::
- Cutting
- Arbor Hole Size::
- 1In(25mm)
- Brand:
- Hoyin Performance
- Color:
- Black
- Commodity Code::
- 6804 22 1000 - Cutting Wheels Bonded Abrasives SYN Resin
- Compatible Tool::
- Stationary Saw
- Country of Origin::
- China
- Diameter::
- 14IN(355mm),16IN(405mm),20IN(505mm)
- For Use With::
- Mounting Nut
- Grade/Hardness::
- S,R
- Grain Type::
- White Aluminum Oxide(WA)
- Grit:
- 30
- Industry:
- Fabrication,Building & Construction
- Material Application:
- Steel/metal,stainless steel
- Maximum RPM::
- 4400,3850,3100
- Product Type::
- Cutting Wheel - HOYIN Aluminium Oxide
- Wheel Thickness::
- 1/8In(3.0mm)
- Wheel Type::
- Type 1
